| Specifications | |
| Motor Size | Φ58.2*H30mm |
| Motor axle diameter | 4mm |
| Operating temperature | -20～50℃ |
| Wire length | 100mm |
| Protection level | IP45 |
| KV | 170 |
| Weight（With wire） | 127g |
| No-load current | 0.4A |
| Resistance | 270mΩ |
| Maximum current (180s) | 15A |
| Max power | 171W |
| Battery | 6-12S |
| ESC | Fortis-R60 |
| Propeller | 17-18inch |
| Technical Parameters | ||||||||
| Throttle[%] | Voltage[V] | Current[A] | Power Input[W] | Power Output[W] | Torque[Nm] | Speed[rpm] | Thrust[g] | Efficiency[g/W] |
| 40 | 47.41 | 1.17 | 55 | 39.0 | 0.13 | 2868 | 682 | 12.34 |
| 45 | 47.39 | 1.57 | 74 | 57.087958115 | 0.17 | 3207 | 849 | 11.43 |
| 50 | 47.36 | 2.1 | 100 | 78.9 | 0.21 | 3588 | 1058 | 10.62 |
| 55 | 47.34 | 2.76 | 131 | 107.593717277 | 0.26 | 3952 | 1285 | 9.84 |
| 60 | 47.31 | 3.46 | 164 | 129.9 | 0.29 | 4279 | 1515 | 9.25 |
| 65 | 47.28 | 4.23 | 200 | 163.021989529 | 0.34 | 4579 | 1739 | 8.7 |
| 70 | 47.24 | 5.11 | 242 | 199.0 | 0.39 | 4872 | 1991 | 8.24 |
| 75 | 47.21 | 6.1 | 288 | 238.291099476 | 0.44 | 5172 | 2234 | 7.76 |
| 80 | 47.17 | 7.2 | 340 | 286.1 | 0.5 | 5465 | 2509 | 7.38 |
| 90 | 47.08 | 9.91 | 466 | 391.151832461 | 0.62 | 6025 | 3116 | 6.68 |
| 100 | 47.03 | 11.46 | 539 | 454.7 | 0.69 | 6294 | 3449 | 6.4 |
